Material Review
Titanium Grade 23 EDM Machining
Titanium Grade 23 is an extra-low-interstitial Ti-6Al-4V grade used where toughness, fatigue and medical cleanliness are important. It is compatible with EDM, while feature access selects Wire, Sinker, Small Hole, or Micro EDM and the supplied condition sets support, finishing, surface control, and inspection.
Quick Answer
Titanium Grade 23 is electrically conductive and can be machined by EDM. Feature access selects the process; the exact condition then sets support, finishing, post-processing, and inspection. The main concern is that surface integrity and traceable post-processing matter more than a generic titanium finish claim.
Key Material Decisions
How This Material Behaves
Its condition changes dimensional stability, discharge response, surface-integrity risk, and the finishing plan.
Choosing the Right Condition
Select Wire EDM for through profiles, Sinker EDM for blind cavities, Small Hole EDM for small or deep holes, and Micro EDM for miniature features. State the exact Titanium Grade 23 condition before assigning tolerance and finish.
Risks to Manage
The main material risk is clear: Surface integrity and traceable post-processing matter more than a generic titanium finish claim. We manage it with condition-aware support, selective finishing, and inspection of the functional faces rather than one whole-part requirement.
How the EDM Route Is Selected
Feature access chooses the EDM route. The supplied Titanium Grade 23 condition then changes support, discharge energy, finishing passes, post-processing, and the method used to verify the result.
Titanium Grade 23 EDM Process Reference
| What you're asking | What you can expect |
|---|---|
| Through profiles | Wire EDM |
| Blind cavities and ribs | Sinker EDM |
| Small or deep holes | Small Hole EDM |
| Miniature holes, slots, or cavities | Micro EDM |
| Material-specific concern | surface integrity and traceable post-processing matter more than a generic titanium finish claim |
Material Condition Reference
| Condition | What to expect | Watch out for | Surface notes |
|---|---|---|---|
| annealed | Use stable support and low-energy finishing. | Thermal surface effects can reduce fatigue resistance. | Specify recast and edge condition on fatigue and medical faces. |
| stress-relieved | Plan around stress relief and thin-wall movement. | Residual stress can distort delicate profiles. | Use trim passes and controlled post-processing on critical faces. |
How This Material Behaves
Titanium Grade 23 is extra-low-interstitial Ti-6Al-4V used where toughness and fatigue performance are tightly controlled. In EDM, this means a contaminated or cracked recast layer can negate the benefit of the ELI grade even when roughness is acceptable. Use clean finishing conditions, leave allowance for surface removal where required, and verify fatigue-critical faces by metallography.
Surface Integrity and Post-Process
For Titanium Grade 23, use low-energy finishing and define whether recast removal, polishing or passivation is required. Mark fatigue, seal, wear, contact, corrosion, or cosmetic faces separately so nonfunctional surfaces are not over-finished.
Titanium Grade 23 Planning Checkpoints
- State the exact grade and supplied condition: annealed and stress-relieved.
- Mark through features, blind forms, holes, and miniature details so each feature is routed to the correct EDM process.
- Identify critical datums, functional surfaces, corrosion protection, and any dimensional or metallurgical inspection.
Typical Parts
- medical components
- aerospace profiles
- lightweight fixtures
- precision instrument features
Limits and Better Alternatives
Main Limit
For Titanium Grade 23, EDM requires a conductive workpiece and offers little advantage on open, loose-tolerance geometry that conventional machining can reach faster. Surface integrity and traceable post-processing matter more than a generic titanium finish claim.
Consider Another Route When
Use CNC or grinding for accessible open geometry and simple precision faces; reserve EDM for hardness, access, sharp corners, deep small holes, and burr-free edges.
Practical Next Step
For a Titanium Grade 23 EDM quote, send the drawing, exact material condition, critical dimensions, functional surface requirements, quantity, and inspection expectations. If the condition or process is uncertain, send the available material specification and drawing for review.
Practical Takeaway
Titanium Grade 23 is suitable for EDM. Feature access selects the process, and the supplied condition determines support, finishing, surface control, and inspection.
Additional Project Information
Include application, destination and end-use notes together with the material, quantity and drawing requirements.
Project Details for Technical Review
Include application and end-use notes when they affect material, inspection, documentation, or export review.
- Material: Titanium Grade 23
- Drawing or part sketch
- Material grade
- Thickness / part size
- Quantity
- Tolerance and critical dimensions
- Surface finish or inspection requirement
STEP/STP, DXF, DWG, PDF, IGS/IGES or ZIP.
Confidential drawing review. NDA support available on request.
Frequently Asked Questions
Can Titanium Grade 23 be machined by EDM?
Yes. Use Wire EDM for through profiles, Sinker EDM for blind cavities, Small Hole EDM for difficult holes, and Micro EDM for miniature features. The process choice follows the geometry, not the material name alone.
How does the condition of Titanium Grade 23 affect the job?
The condition changes support, residual-stress response, finishing energy, dimensional stability, and surface-integrity requirements. State the supplied condition; if it is unknown, send the material specification.
What is the main risk with Titanium Grade 23?
Surface integrity and traceable post-processing matter more than a generic titanium finish claim. We manage this with condition-aware fixturing, appropriate finishing energy, and process-specific inspection on the functional faces.
What information is needed for a quote?
Send the drawing, exact Titanium Grade 23 condition, critical dimensions, surface requirements, quantity, and inspection expectations. If some details are unknown, send what you have and we will help complete the review.
